Renthal Integra II 45 mm Stem - 31.8 MM

Description

Features

Specs

Description

Renthal’s revolutionary Integra 35 stem combines high strength with ultra-low weight.

The use of two independent, C-shape handlebar clamps allows the stem body material to be reduced to a minimum, whilst maintaining an incredibly stiff and strong structure.

The ultra-wide, 64mm handlebar clamping area increases torsional rigidity and the use of just six bolts vastly reduces overall weight.

In addition, the uninterrupted clamp on the underside of the handlebar eliminates stress risers found on most other clamps, which can lead to handlebar failure.

Features

CNC Machined

The Renthal Integra 35 features a CNC machined 6082 T6 aluminium body and 7075 clamps. The materials have been specifically chosen, to give the highest strength to weight ratio.

Six Bolt Configuration

Steel hardware is a major factor in the weight of a stem. The Integra 35 has reduced the required hardware to just six bolts, instead of the normal eight, to vastly reduce overall weight.

Size Options

The Integra 35 is available in four different size options, each individually designed to maximise the strength to weight ratio.

C-Shape Clamps

The use of two independent, C-shape handlebar clamps allows the stem body material to be reduced to a minimum, whilst maintaining an incredibly stiff and strong structure.

Ultra Wide

The 64mm wide clamp gives superior strength and structural stability. This increases control, without the need to add large amounts of material and hence weight.

High Quality Finish

After CNC machining, all components of the stem are anodised and laser marked to give a very high quality and durable finish.

Specs

	STM113-BKAG	STM114-BKAG	STM115-BKAG	STM116-BKAG
Length	45mm	45mm	50mm	50mm
Rise	0mm	+10mm	0mm	+10mm
Weight	133g	156g	157g	177g
