Frame

• Frame: 6061 Aluminum, BSA BB, Disc Brake Mount, Integrated 1-1/8"-1.5" Taper H/T, 3/8" Horizontal Adjustable Dropout w/ Integrated Chain Tensioners

• Sizes Available: One Size

• Fork: Manitou Machete J-Unit, Air Spring w/ Rebound Adjust, 15mm Thru Axle Dropout, 1-1/8"-1.5" Taper AL Steerer, Pre Load Adjust, Black Stanchions

• Wheel Size: 24

Wheels

• Rims: Alloy Double Wall, 32h

• Front Hub: Sealed Alloy Disc, 15x110 Boost

• Rear Hub: Alloy Disc Body, Sealed Bearings, 32 Hole, 3/8" x 17mm Female Bolt

• Front Tire: Kenda Small Block Eight 2.10"

• Rear Tire: Kenda Small Block Eight 2.10"

• Spokes: Stainless Steel, 14g

Drivetrain

• Rear Cogs: 13T Cog

• Chain: KMC HL1 Wide

• Crank: GT Power Series 3pc Chromoly 140mm, 19mm x 8T Spindle, GT NBS 28T Alloy Chainwheel

• Bottom Bracket: BSA Sealed

• Pedals: GT Logo PC Platform

Cockpit

• Handlebar: GT Alloy Riser Bar, 30mm Rise, 650mm Wide, 5° Up, 9° Back

• Stem: GT 3D Forged Alloy Stem 35mm, 31.8mm Clamp

• Grips: GT Super Soft Flanged

• Headset: 1-1/8-1.5" Taper Sealed Integrated, (45)

• Seatpost: Alloy Pivotal 27.2 x 200mm

• Saddle: GT Pivotal Slim Padded

Brakes

• Brakes: Hydro Disc, 160mm Rotor (F/R)

• Brake Levers: Brake Levers Alloy, 2 Finger Hydro

• Please note that, based on component availability and other factors, specifications are subject to change without notice.

Geometry
