If you’re a hardy adventure-seeker who doesn’t subscribe to the concept of labels, you’ve come to the right place. Whether you’ve put in months of planning, or you just decided to turn right on a whim, the Search XR A1 is built to thrive off the beaten path and is up to whatever adventure you chase.
ROAD
Adventure Seeker. The Search XR Aluminum is up for whatever spontaneous, uncharted, off-piste adventure you can conjure. Whether you’ve put in months of planning, or you simply decided to turn right on a whim, there’s a Search XR built to thrive wherever your adventurous spirit and love of the long haul take you.
ALUMINUM FRAME
Sure footed versatility to take you anywhere. The smooth welded, ultra-capable aluminum frame makes for a robust, elegant looking adventure rig that maximizes comfort and reduces fatigue.
MULTIPLE CONFIGURATIONS
Unique layouts and frame geometries for different riders. Frame geometries differ between flared drop bar, flat bar and suspension-equipped models to ensure you get precisely the ride you want with the setup you prefer.
ADVENTURE DESIGN
All-out performance in harsh conditions. The Search XR geometry is a little slacker and longer than your typical Gravel machine and each model is tuned specifically for the riding you dig and the adventure you chase.
INTERNAL ROUTING
Sleek lines and reduced maintenance. Internal routing with adaptable port covers keeps cables tight and secure and prevents moisture from creepin’ in. The Search XR is also compatible with a wide range of modern drivetrains.
CUSTOM RIDE
Size-specific tubing for tuned rider experience. Tube dimensions and materials are engineered to provide similar ride qualities to everyone, whatever their height or power output.
TIRE CLEARANCE
More clearance opens up a wide variety of rides. Big tires offer comfort and control on paved surfaces and greater traction off-road excursions. Optimize your Search XR to your favorite kind of ride with clearance for up 50mm rubber.
|
FRAME |
Butted Aluminum, Smooth Welds |
|
FORK |
Full Carbon, Through Axle |
Drivetrain
|
REAR SHIFTER |
Shimano Tiagra ST-4700 |
|
REAR DERAILLEUR |
Shimano GRX RD-RX400 Shadow RD+ |
|
FRONT SHIFTER |
Shimano Tiagra ST-4700 |
|
FRONT DERAILLEUR |
Shimano GRX FD-RX400 |
|
CRANKSET |
FSA Omega Modular 46/30 AGX+, 170mm (49, 52), 172.5mm (55, 58), 175mm (61) |
|
BOTTOM BRACKET |
FSA BB386EVO for BSA |
|
CASSETTE |
Shimano CS-HG50, 11-36T, 10 Speed |
|
CHAIN |
KMC X10 |
Brakes
|
FRONT BRAKE |
Tektro MD-C550 Dual-Piston Mechanical Disc, Resin Pads |
|
FRONT BRAKE ROTOR |
Tektro 6-Bolt, 160mm |
|
REAR BRAKE |
Tektro MD-C550 Dual-Piston Mechanical Disc, Resin Pads |
|
REAR BRAKE ROTOR |
Tektro 6-Bolt, 160mm |
|
BRAKE LEVERS |
Shimano Tiagra ST-4700 |
Components
|
HANDLEBAR |
Norco Super Flare Aluminum, 16 Degree Flare, 40cm (49), 42cm (52), 44cm (55), 46cm (58, 61) |
|
STEM |
Norco SL Aluminum, 31.8mm Clamp, 70mm (49), 80mm (52), 90mm (55), 100mm (58), 110mm (61) |
|
SEATPOST |
Aluminum 27.2mm |
|
HEADSET |
Sealed Cartridge Bearing |
|
HEADSET SPACER |
3x10mm Aluminum |
|
SADDLE |
Selle Royal Gravel with Cutout |
|
GRIPS |
Griptacular Shockproof Tape |
|
PEDALS |
City Resin |
|
SEATPOST CLAMP |
Aluminum 31.8mm |
Wheels
|
FRONT HUB |
12x100mm Through Axle, 6 Bolt |
|
REAR HUB |
12x142mm Through Axle, HG, 6 Bolt |
|
RIMS |
Alloy Pinned, 28H, 23mm ID |
|
FRONT TIRE |
Vittoria Terreno Dry 700x38c |
|
REAR TIRE |
Vittoria Terreno Dry 700x38c |
|
REAR HUB SKEWER |
Tooled 12x142mm Thru-Axle |
|
FRONT HUB SKEWER |
Tooled 12x100mm Thru-Axle |
|
SPOKES/NIPPLES |
Sapim Leader, Black |
|
VALVES |
Standard |
|
RIM TAPE |
Nylon |
Geometry
|
45.5 |
48 |
50.5 |
53 |
55.5 |
58 |
60.5 |
||
|
Wheel Size |
650b |
650b |
700c |
700c |
700c |
700c |
700c |
|
|
Reach |
355 |
362 |
376 |
383 |
390 |
399 |
407 |
|
|
Stack |
504 |
524 |
547 |
563 |
580 |
600 |
620 |
|
|
HTA |
Head Tube Angle |
70.75 |
71.00 |
71.50 |
71.75 |
72.00 |
72.25 |
|
|
OS |
Fork Offset |
49 |
||||||
|
ST |
Seat Tube Length |
410 |
435 |
460 |
490 |
520 |
550 |
580 |
|
STA |
Effective Seat Tube Angle |
74.00 |
73.75 |
74.25 |
73.75 |
73.25 |
73.00 |
72.75 |
|
RC |
Rear Centre Length |
410.0 |
422.5 |
425.0 |
||||
|
BB |
Bottom Bracket Rise/Drop |
-57.0 |
-75.0 |
-72.5 |
-70.0 |
|||
|
BBH |
Bottom Bracket Height |
275 |
279 |
282 |
284 |
|||
|
HTT |
Horizontal Top Tube |
500 |
515 |
530 |
548 |
565 |
583 |
600 |
|
WB |
Wheelbase |
970 |
981 |
1006 |
1015 |
1028 |
1042 |
1054 |
|
SOH |
Standover |
635 |
658 |
687 |
717 |
744 |
775 |
802 |
|
HT |
Head Tube Length |
110.0 |
130.0 |
120.0 |
137.5 |
155.0 |
177.5 |
197.5 |
|
Trail |
64 |
62 |
70 |
67 |
65 |
63 |
62 |
|
|
Stem Length |
80 |
90 |
100 |
110 |
||||
|
Crank Length |
165.0 |
170.0 |
172.5 |
175.0 |
||||
|
Max 700c Tire Size (* w/ Fender) |
40 (*35) |
|||||||
|
Max 650b Tire Size (* w/ Fender) |
47 (*38) |
51 (*48) |
||||||
|
Max 26" Tire Size (* w/ Fender) |
2.1" (*2.1") |
|||||||
