The best of all worlds. Do it all with the Patron eRIDE 930. Ready to tackle any climb with ease and scream back down with sure footed and confidence inspiring handling. 150mm of front and rear travel gobbles up the terrain while our TracLoc technology allows you to adjust the suspension on the fly to give you an efficient ride in all conditions. Careful engineering and design makes this E-Bike a dream to work on with clever integration, easily removable battery and great access to the shock.
The cover keeps everything clean, reducing service intervals. The alloy bomb proof frame will keep you rolling no matter what. Being an E-Bike, the Bosch CX drive unit provides up to 100Nm of power while the 800Wh battery gives you the range to conquer any ride from time crunched hour of power to all day epics. The decision is yours. *Please note that bike specifications are subject to change without prior notice.
MOTOR & BATTERY
For the mountain biker looking to unlock new zones and ride more terrain than ever, the Patron eRIDE holsters the cutting edge of full-power motor and battery technology in a package built for singletrack domination. With the latest Bosch Performance CX drive unit paired with the 800Wh Powertube battery, the Patron is your ticket to freedom in the mountains.
HANDLEBAR DISPLAY
Connectivity, flexibility and visibility are the key words for the Kiox 300 and the LED Mini Remote. The Kiox is a 2’’ colored screen integrated in the stem. It displays all necessary info including speed, GPS, cadence and a Bluetooth connection to the eBike Flow App. You don’t want to have a screen on your handlebar? You can take it off and control everything from the LED remote or your phone. The new LED remote, displays the current charge status and allows an easy switch from one mode to the other. The ambient light sensor automatically controls the brightness of the LEDs. In order to minimize distractions when you’re getting rowdy, all ST models opt for just the Mini Remote and Sytem controller, without the addition of the display. All key metrics can still be tracked and displayed via a cycling computer of your choice.
PATENTED INTEGRATED SHOCK TECHNOLOGY
A stellar day on the trails begins with stellar suspension design, and the Patron’s 150mm of integrated travel will keep you tracking the ground smoothly no matter the terrain. Integrating the shock has allowed us to achieve desired shock characteristics, while also granting us the space to ideally position elements such as the motor, the battery and a water bottle. Riding a range of varied terrain? The TracLoc remote on the handlebar alters suspension characteristics with just a push of the thumb, allowing you to match your suspension to the trail ahead.
FRAME CONSTRUCTION
The Patron eRIDE lineup features carbon and alloy models, both meticulously engineered to harness the unique characteristics of each material. Subjected to the highest degree of testing and numerous iterations in the development phase, the Patron eRIDE exhibits the perfect blend of stiffness and strength and weight distribution to lead to an unmatched ride feel - especially when things get rough.
ACCESSORIES & COMPATIBILITIES
Featuring tailor made details such as integrated fender and LED rear lights, the Patron eRIDE has been developed to be a “just get on and ride” kind of bike. To take this a step further, the Patron is pre-wired and ready for you to link up a front light to the main battery if you desire. A range of Syncros accessories are also available for the Patron eRIDE such as a kickstand, a rear rack or an action camera mount.
CABLE INTEGRATION
Fact: With E-bikes come cables. Thankfully, on the Patron eRIDE, these are all cleanly integrated into the frame to hide them from sight, protect them from the elements and ensure no unnecessary bends impede on their function.
FRAME: Alloy Frame, Integrated Suspension Technology, Virtual 4 Link kinematic, Adjustable head angle, Syncros Cable Integration System, Bosch Smart System, UDH Interface, 12x148mm with 55mm Chainline, Bosch PowerMore Ready
TRAVEL: Front: 150mm, Rear: 150mm
FORK: RockShox Psylo Silver RC Air, E-Bike, Comp & Reb Adj., QR Axle 15x110mm axle, 44mm offset, tapered steerer, 150mm travel
REAR SHOCK: X-Fusion O2 Trunnion PRO RL, Lockout, Reb. Adj., T185X55mm
DRIVE UNIT: EU: 25kmh, INT: 20mph, Bosch Performance Line CX (BDU384Y)
BATTERY: PowerTube 800Wh
DISPLAY: Bosch System Controller, Mini Remote
CHARGER: 2A Charger
REAR DERAILLEUR: Shimano Deore RD-M6100 SGS, Shadow Plus, 12 Speed
SHIFTERS: Shimano Deore SL-M6100-IR, Rapidfire Plus
CRANKSET: FSA Alloy
CHAINGUIDE: e*thirteen, e*spec Slider
CHAINRING: FSA 12 Speed 34T chainring
CHAIN: Shimano CN-M6100
CASSETTE: Shimano CS-M6100, 10-51
BRAKES: Shimano MT420 4 Piston Disc
ROTOR: Front: SM-RT64 CL 220mm, Rear: SM-RT64 CL 203mm
HANDLEBAR: Syncros Hixon 2.0 Alloy 6061, Size S & M 15mm rise, Size L & XL 25mm rise, back sweep 8°, 780mm, Syncros Performance XC lock-on grips
H'STEM: Syncros AM 2.0, Syncros Cable Integration System, 4° rise, 6061 Alloy, 31.8mm, 1 1/8"
SEATPOST: Syncros Duncan Dropper Post 2.5, 31.6mm, S size 125mm, M size 150mm, L size 170mm, XL size 200mm
SEAT: Syncros Tofino 2.5 Regular
HEADSET: Syncros - Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
HUB (FRONT): Formula CL-811, 15x110mm
HUB (REAR): Formula ECT-148M, Boost 148x12mm
SPOKES: Stainless Black
RIMS: Syncros MD30, 32H, 30mm, Pin Joint, Tubeless ready
FRONT TIRE: Maxxis Forekaster 29x2.6", 120TPI Foldable Bead, EXO, TR Tubeless ready, 3C Maxx Terra
REAR TIRE: Maxxis Forekaster 29x2.6", 120TPI Foldable Bead
EXO, TR Tubeless ready: 3C Maxx Terra
LIGHTS: Syncros integrated rear fender light, Front Light Cable pre-installed
APPROX WEIGHT IN KG: 25.8
APPROX WEIGHT IN LBS: 56.88
MAX. SYSTEM WEIGHT: 130kg
The overall weight includes the bike, the rider, the equipment, and possible additional luggage.
Geometry
|
S |
M |
L |
XL |
||
|
A |
HEAD TUBE ANGLE / ANGLE TUBE DE DIRECTION |
65.8 ° |
65.8 ° |
65.8 ° |
65.8 ° |
|
B |
HEAD TUBE LENGTH / HAUTEUR TUBE DE DIRECTION |
4.7 IN |
4.9 IN |
5.3 IN |
5.7 IN |
|
C |
TOP TUBE HORIZONTAL / LONGUEUR HORIZONTALE TUBE SUPÉRIEUR |
22.8 IN |
23.8 IN |
24.7 IN |
25.9 IN |
|
D |
STANDOVER HEIGHT / HAUTEUR ENTRE-JAMBES |
28.3 IN |
28.3 IN |
28.7 IN |
28.8 IN |
|
E |
BB OFFSET / DEPORT AXE DE PÉDALIER |
-1.4 IN |
-1.4 IN |
-1.4 IN |
-1.4 IN |
|
F |
BB HEIGHT / HAUTEUR AXE DE PÉDALIER |
13.4 IN |
13.4 IN |
13.4 IN |
13.4 IN |
|
G |
WHEEL BASE / ENTRAXE ROUES |
47.7 IN |
48.6 IN |
49.8 IN |
51.1 IN |
|
H |
BB CENTER TO TOPTUBE CENTER / DIST. BOITIER - MILIEU TUBE SUPÉRIEUR |
||||
|
I |
BB CENTER TO TOP OF SEATTUBE / DIST. BOITIER - SOMMET TUBE DE SELLE |
15.9 IN |
17.1 IN |
18.5 IN |
19.7 IN |
|
J |
SEAT ANGLE / ANGLE TUBE DE SELLE |
77.4 ° |
77.2 ° |
77.2 ° |
77.2 ° |
|
K |
CHAINSTAY / LONGUEUR DES BASES |
17.9 IN |
17.9 IN |
17.9 IN |
17.9 IN |
|
L |
REACH / REACH |
17.3 IN |
18.1 IN |
19.1 IN |
20.2 IN |
|
M |
STACK / STACK |
25.3 IN |
25.5 IN |
25.8 IN |
26.2 IN |
|
N |
STEM LENGTH / LONGUEUR POTENCE |
2.0 IN |
2.0 IN |
2.0 IN |
2.0 IN |
|
0 |
TRAIL / CHASSE AU SOL |
4.7 IN |
4.7 IN |
4.8 IN |
4.8 IN |
|
P |
FORK LENGTH / LONGUEUR FOURCHE |
22.1 IN |
22.1 IN |
22.1 IN |
22.1 IN |
|
Q |
MAXIMUM SEATPOST INSERTION / INSERTION MAXIMALE DE LA TIGE DE SELLE |
7.9 IN |
9.1 IN |
10.4 IN |
11.6 IN |
|
R |
CRANK LENGTH / LONGUEUR DE MANIVELLE |
6.5 IN |
6.5 IN |
6.5 IN |
6.5 IN |
