Shimano BL-M8100 & BR-M8100 DEORE XT Rear Disc Brake Assembled Set Black

Shimano BL-M8100 & BR-M8100 DEORE XT Rear Disc Brake Assembled Set

Name: Shimano BL-M8100 & BR-M8100 DEORE XT Rear Disc Brake Assembled Set
Brand: Shimano
SKU: IM8100JRRXNA170
Price: 229.99 CAD
Availability: InStock

$229.99

RETURNS

MADE EASY

PROUDLY

CANADIAN

BEST PRICE

GUARANTEE

Description

Features

Specs

Description

The SHIMANO DEORE XT M8100 caliper features lightweight braking performance and reliable stopping power in all conditions. With a focus on reduced weight and cross-country tuned stopping power, the SHIMANO DEORE XT BL-M8100 lever provides intuitive modulation so that you can explore your limits with confidence.

Features

BR-M8100 Features

Superior modulation gives you greater control
Quicker Piston retraction
Lightweight
Two piston
Quick and easy assembly
Banjo type connection and inside hose routing

BL-M8100 Features

Intuitive and versatile braking keeps your focus on the trail
Optimized lever axle position with additional contact point and refined ergonomics
Greater flexibility and action-optimized cockpit layout
I-SPEC EV
High rigidity
10% stiffer than M8000 even under high temp conditions
Quicker brake engagement with shorter free stroke
Rider tuned adjustment
Toolless reach adjust
Free stroke adjust

Specs

MODEL NO	BR-M8100
SERIES	DEORE XT M8100 Series
Color	Series color
Average weight	392

ICE TECHNOLOGIES pad compatible caliper	✔
Brake hose color (kit)	Black
Brake hose (Kit)	SM-BH90-SBM
Brake type	Hydraulic disc brake
Caliper fixing bolt_Anti loosen method	Snap ring
Caliper fixing bolt_Tool size	5 mm
Hose joint	Banjo
Mount type	Post-type
ONE WAY BLEEDING	✔
Pad_Option	J03A Resin (w/ fin) \| J04C Metal (w/ fin)
Pad_Standard	G03A Resin (w/o fin) \| G04S Metal (w/o fin)
Pad mount	Pad axle
Piston	2
Recommended brake lever	BL-M8100 BL-T8100
Recommended disc brake rotor	RT-MT800
J-Kit spec (for OEM)	✔
Oil	SHIMANO Mineral
Compatible Brake Rotor Size_140 mm (SS)	✔
Compatible Brake Rotor Size_160 mm (S)	✔
Compatible Brake Rotor Size_180 mm (M)	✔
Compatible Brake Rotor Size_203 mm (L)	✔
Pad_Option 1	J03A Resin (w/ fin)
Pad_Option 2	J04C Metal (w/ fin)
Pad_Standard 1	G03A Resin (w/o fin)
Pad_Standard 2	G04S Metal (w/o fin)

MODEL NO	BL-M8100
SERIES	DEORE XT M8100 Series
Color	Series color
Average weight	392 (BR-M8100) 410 (BR-M8120)

Brake hose color (kit)	Black
Brake hose (Kit)	SM-BH90-SBM
Brake type	Hydraulic disc brake
Hose joint	Straight
Compatible shift lever mount_I-SPEC EV	✔
Free stroke adjust	✔
Funnel bleeding	✔
J-Kit spec (for OEM)	✔
Lever size (finger)	2
Oil	SHIMANO Mineral
Reach adjust_Toolless	✔
Recommended brake caliper	BR-M8100 BR-M8110 BR-M8120
SERVO WAVE	✔
Compatible shift lever mount_Clamp band	✔
Clamp band_Open clamp	✔
Shift lever rotation angle adjust range (I-SPEC EV ; deg.)	20
